Piezoelectric Wafer 5mol Percent 5mol% Doped Lithium Niobate LiNbO3 Wafers for Photonics and Telecommunications Applications
Подробная информация о продукте:
| Место происхождения: | Китай |
| Фирменное наименование: | CQT |
| Сертификация: | ISO:9001, ISO:14001 |
| Номер модели: | Ниобат лития (LiNbO3) |
Оплата и доставка Условия:
| Количество мин заказа: | 10 шт |
|---|---|
| Цена: | Подлежит обсуждению |
| Упаковывая детали: | Пакет опарника кассеты, вакуум загерметизировал |
| Время доставки: | 1-4 недели |
| Условия оплаты: | Т/Т |
| Поставка способности: | 20000 ПК/месяц |
|
Подробная информация |
|||
| Материал: | Вафля LiNbO3 | Диаметр: | 3'', 4' |
|---|---|---|---|
| Ориентация: | Х, З и т.д. | Допинг: | 5% MgO:LN |
| Толщина: | 250ум 300ум 500ум 1000ум | Чистота поверхности: | DSP, SSP, притирка |
| Оценка: | Оптически ранг | Приложение: | SAW фильтр, ультразвуковой преобразователь |
| Выделить: | 5mol% doped lithium niobate wafer,piezoelectric wafer for photonics,LiNbO3 wafer for telecommunications |
||
Характер продукции
Piezoelectric Wafer 5mol Percent 5mol% Doped Lithium Niobate LiNbO3 Wafers for Photonics and Telecommunications Applications
Unlock superior electro-optic, acousto-optic, and nonlinear optical properties with our cutting-edge 5mol% doped lithium niobate (LiNbO₃) wafers. Engineered to outperform standard LiNbO₃, these wafers incorporate precisely controlled dopants to reduce optical losses, enhance photorefractive resistance, and improve thermal stability—critical for high-power and high-speed applications.
Ideal for advanced telecommunications, quantum optics, and laser technologies, our 5mol% doped wafers feature ultra-low absorption coefficients and high electro-optic coefficients (r₃₃ > 30 pm/V), enabling faster modulation speeds and lower driving voltages in fiber-optic systems and LiDAR. Their improved damage threshold and reduced coercive fields also make them perfect for nonlinear frequency conversion (e.g., SHG, OPO) and integrated photonics.
Precision-manufactured in X-cut, Y-cut, or Z-cut orientations with customizable diameters and thicknesses, each wafer undergoes rigorous quality testing to ensure surface flatness and minimal defects.
Elevate your optoelectronic innovations with our 5mol% doped LiNbO₃ wafers. Contact us today to discuss your specifications and harness the full potential of this enhanced material.
Precision Doping. Superior Performance.
|
Material |
3" 4" 6" 8" LN wafer (Saw/Optical grade) |
|
Orientation Cut |
Y64°, Y128°, YZ or Customized |
|
Surface finish |
single or double sides polish (DLP/SLP/ SSP/DSP all available ) |
|
Thickness |
0.18/0.25/0.35/0.50/1.00 + mm |
|
TTV |
< 1~5µm |
|
BOW |
± (25µm ~40um ) |
|
Warp |
<= 35µm |
|
LTV (5mmx5mm) |
<1.5 um |
|
PLTV(<0.5um) |
≥98% (5mm*5mm) with 2mm edge excluded |
|
Curie Temp |
1142°C±3°C |
|
Edge Rouding |
Compl't with SEMI M1.2@with GC800# .regular at C typed |
|
Orientation flats |
available, per request |
|
Polished side Ra |
Roughness Ra<=5A |
|
Back Side Criteria |
Roughness Ra:0.5-1.0µm GC#1000 |
|
Cracks, saw marks, stains |
None |
|
Single Domain |
Completed Polarization/Reduced |
FAQs:
- Q: Can you accept product customization?
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
- Q: Can you deliver the goods via our courier agent?
A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.
Acceptance Check
- The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
- After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
- Please open the vacuum package in a clean room when the products are to be applied.
- If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
